VOLTRX Shaker Manual

How to Use VOLTRX Eletric Shaker Bottle?


  1. After unpacking, be sure to fully charge the product before use. When charging, the base LED lights to indicate the current battery level. When the battery is fully charged, all the LED will turn off.
  2. Three easy steps!
    • Add Liquid: Fill your VOLTRX with the liquid of your choice. Ideal fill = 250-400ml (9-14oz)
    • Add Protein / Supplement Powder: Pour liquid or powdered supplement into VOLTRX(up to 60g).
    • Active ur VOLTRX Shaker Bottle: Push button to activate.
  1. Tighten the lid and enjoy your drink.

Operating Modes

Power Button

Mode Operation Action
1 single press 30-second stir
2 double press 3-minute stir
3 long press 2 seconds show battery level
4 single press during stirring stop stirring

Product Introduction

Product Information

Product Model VortexBoost


markings goes to 20oz(600ml)

Size 3.6×3.6×9.4 inches
Weight 0.55lb
Wall Material Type Eastman Tritan
Cap material Type PP
Water Resistance IPX5
Working Current 500mA
Rate Power 2.5watts
Battery Type Li-Polymer
Battery Capacity 700mA
Normal Voltage 3.7V
Charging Time more than 1.5 hours


Important Notes

  1. To avoid damage and injury, do not pour water over a 160 Fahrenheit into the bottle. Too high a temperature will cause a pressure buildup during operation, which may break the seal and gush out the top.
  2. Do not put the cup in the microwave oven, disinfection cabinet and other high temperature environment to heat. Do not freeze this product.
  3. Do not add dry ice, carbonated drinks and other liquids prone to high pressure. Do not add strong acid and alkali to prevent the inner wall of the container from corrosion.
  4. Do not store dairy products or baby food in cups for a long time.
  5. Please avoid contact with this product by children to avoid damage or liquid overflow.
  6. Do not immerse the base completely in liquid for a long time to avoid failure.

Battery Energy

  1. Battery life largely depends on how often you use it. The 1 charge 1 month claim is calculated based on the 30 second stirring mode used three times a week.
  2. Charge with micro android cable. The product can be charged with 1A and 2A current.
  3. When charging, the LED indicator will flicker at the current battery level, and all the indicator lights will be off when fully charged.
  4. It takes about 2 hours for the battery to be fully charged after the battery is completely exhausted.
  5. To ensure safety, the motor cannot be started when charging.
  6. At the end of mixing, if the LED indicator lights go out successively, and all the LED lights flash rapidly for 5 times, it means the battery should be charged.


Failure performance Possible Reason
unable to start stirring

in charging state

low power

base and cup are not installed in position

weak stirring power

low power

too much shakes

base and cup are not installed in position

the base and cup cannot be assembled

foreign body in the slot

slot is not located correctly

Feel to contact us if any assistant need and e-mail at [email protected]

How to clean?

Cleaning method

  1. Use neutral detergent or water to clean the cup.
  2. Add adequate amount of water to the cup and turn on the stirring function to clean the inside of the cup.
  3. The base is waterproofed to IPX5 (IPX5 accepts normal water flow and cannot be completely submerged for long periods of time). To prevent short circuit, remove the base before cleaning.

Open the lid

Clean the interior

Base removal method

  1. Before washing or placing the cup in the dishwasher, remove the base to prevent water from entering the motor.
  2. To remove the base, hold the cup with your left hand, hold the base with your right hand and rotate to the left to remove the base.(as shown below)
  3. After cleaning, please keep the gear dry, otherwise the mixing efficiency will be reduced.
  4. After removing the base, do not remove the gear and silica gel at the bottom of the cup, otherwise, the mixing efficiency will be reduced.
  5. After the base is reinstalled, make sure the buttons are aligned with the center of the LOGO, otherwise the mixing efficiency will be reduced.
  6. If the base falls into the water accidentally, dry the surface of the base and then blow dry the inside of the base with an air blower. Normally, the motor can continue to work.


  • Strong Power

Our have-duty moto, assembled with industry leading technology, spins at 2000rpm, ensuring smooth mixing with no lumpiness. Helps the body absorb nutrients more efficiently.

  • Insane 1 month of use from a 2-hour charge

Enjoy a year of battery life with just one charge (based on three times a week usage pattern). Powerful motor ensures no remaining chunks (performance may drop slightly when charge is low).

  • Wide mouth makes it easy to add mix scoops and liquids

Screw-on lid creates leak-proof seal and secure flip cap keeps germs at bay; Wide loop top for easy carrying or attaching keys.

  • Infant Grade Eastman Tritan

Made of BPA and phthalate-free, stain and odor resistant durable Eastman Tritan plastic.
